300M Coil PERT AL PERT Fittings Pipe, Multilayer Pipe

Hot SKU: UHPI-SPAP16300 In Stock: 190 Categories: Underfloor Heating Pipes

Introductory Offer

216.82 Excl.VAT


Choose Quantity:
Buy Now Add to cart


300M, 16MM Coil Pert Al Pert Pipe

Our range of pert-al-pert pipe is manufactured to ISO9001 European standards ensuring outstanding performance & reliability.

5 layer 16mm pert-al-pert pipe is used in all of our warm water underfloor heating kits and offers unrivaled suitability for underfloor heating by combining the best elements of a plastic and metal pipe into one product.

The aluminium core provides strength and importantly acts as an oxygen barrier to stop the ingress of oxygen into the system causing premature wear (corrosion) to the manifold. The aluminium layer also makes the pipe form-stable, making it very easy to work with by eliminating spring back for easier installation.

Pert-Al-Pert pipe key features:

  1. 5 layer composite pipe using PE-RT inner and outer layers with a 0.25mm thick edge-welded aluminium core

  2. Butted welded manufacturing method

  3. Can be formed by hand and maintains its shape- perfect for underfloor heating pipework

  4. High temperature resistance- a maximum sustained working temp up to 70°c & maximum transient temperature up to 85°c

  5. Manufactured to meet CE & ISO9001 European & International standards

Technical Data

Pipe range nominal dimensions16mm OD 2mm wall thickness
Sustained max working temp70°c
Min/Max temperature-40°c – 85°c
Construction 5 layerPert, adhesive, aluminium, adhesive, pert
TypeButt welded
Bend radius≥8D
Oxygen permeability≤0.32mg/(m.d)
Thermal conductivity 0.40w/m.k
ApplicationUnderfloor heating
Manufacturing standardsEN ISO22391-2:2009, ISO9001, CE, TUV SUD, ISO14001
